THE Z4
BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.
THE Z4BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.
The key facts and figures for the BMW Z4 Roadster at a glance:
- Engines, consumption and CO2 emissions
- Performance data such as displacement, kW/hp, torque and acceleration
- Weight, dimensions, wheel and tyre sizes
BMW Z4 ROADSTER: TECHNICAL DATA.
Select model
- BMW Z4 sDrive20i(1)
- BMW Z4 sDrive30i(1)
- BMW Z4 M40i(1)
No search result found. Please try another input
| Unladen weight EU in kg | 1,495-1,480 [1,505-1,495] |
|---|---|
| Max. permissible weight in kg | 1,725 [1,740] |
| Permitted load in kg | 305-320 [310-320] |
| Permitted axle load front/rear in kg | 830/935 [830/935] |
| Luggage capacity min. (seats up or roof down) in l | 281 [281] |
| Luggage capacity max. (seats down or roof up) in l | 281 [281] |
| Trailer load (unbraked) in kg | - [-] |
| Trailer load 12% (braked) in kg | - [-] |
| Trailer load 8% (braked) in kg | - [-] |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 145 (197)/4,500-6,500 |
| Engine torque (Nm) at 1/min | 320/1,450-4,200 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 241 [240] |
|---|---|
| Acceleration 0–100 km/h in s | 6.8 [6.6] |
| Urban in l/100 km | 9.3 [7.8] |
|---|---|
| Extra-urban in l/100 km | 6.0 [5.7] |
| Combined in l/100 km | 7.2 [6.5] |
| CO2 combined emissions in g/km | 165 [148] |
| Tank capacity, approx. in l | 52 |
| Tyre dimensions front | 225/50 R17 94 W |
|---|---|
| Tyre dimensions rear | 255/45 R17 98 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 8.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1.505 |
|---|---|
| Max. permissible weight in kg | 1,740 |
| Permitted load in kg | 310 |
| Permitted axle load front/rear in kg | 830/935 |
| Luggage capacity min. (seats up or roof down) in l | 281 |
| Luggage capacity max. (seats down or roof up) in l | 281 |
| Trailer load (unbraked) in kg | - |
| Trailer load 12% (braked) in kg | - |
| Trailer load 8% (braked) in kg | - |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 190 (258)/5,000-6,500 |
| Engine torque (Nm) at 1/min | 400/1,550-4,400 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 5.4 |
| Urban in l/100 km | 7.9 |
|---|---|
| Extra-urban in l/100 km | 5.7 |
| Combined in l/100 km | 6.5 |
| CO2 combined emissions in g/km | 149 |
| Tank capacity, approx. in l | 52 |
| Tyre dimensions front | 225/50 R17 94 W |
|---|---|
| Tyre dimensions rear | 255/45 R17 98 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 8.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,630-1,610 |
|---|---|
| Max. permissible weight in kg | 1,860 |
| Permitted load in kg | 305-325 |
| Permitted axle load front/rear in kg | 865/995 |
| Luggage capacity min. (seats up or roof down) in l | 281 |
| Luggage capacity max. (seats down or roof up) in l | 281 |
| Trailer load (unbraked) in kg | - |
| Trailer load 12% (braked) in kg | - |
| Trailer load 8% (braked) in kg | - |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 250-285 (340-387)/5,000-6,500 |
| Engine torque (Nm) at 1/min | 500/1,600-5,000 |
| Compression ratio : 1 | 11.0-10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 4.5-4.1 |
| Urban in l/100 km | 9.8 |
|---|---|
| Extra-urban in l/100 km | 6.2 |
| Combined in l/100 km | 7.5 |
| CO2 combined emissions in g/km | 171 |
| Tank capacity, approx. in l | 52 |
| Tyre dimensions front | 255/40 ZR18 95 Y |
|---|---|
| Tyre dimensions rear | 275/40 ZR18 99 Y |
| Wheel dimensions and material front | 9 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 10 J x 18 inches, light-alloy |
Including of /content/bmw/marketMASTER_DS2/global_master/en_MS/publicPools/teaser-pool/medium-teasers/tyre-energy-lables/jcr:content/par-4col/wideteaser_67 failed
Fuel consumption and CO2 emissions.
- Disclaimer reference invalid
Fuel consumption and CO2 emissions.
BMW Z4 Roadster M40i:
Fuel consumption, combined NEDC in l/100 km : 7.5
CO2 emissions, combined NEDC in g/km : 171
The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.
The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/e10.
The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.
[1] Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.
