BMW X2: ENGINES & TECHNICAL DATA
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW X2.
THE X2BMW X2: ENGINES & TECHNICAL DATA
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW X2.
BMW X2: TECHNICAL DATA.
Select model
- BMW X2 sDrive18i
- BMW X2 sDrive20i
- BMW X2 xDrive20i
- BMW X2 M35i
- BMW X2 sDrive16d
- BMW X2 sDrive18d
- BMW X2 xDrive18d
- BMW X2 sDrive20d
- BMW X2 xDrive20d
- BMW X2 xDrive25d
No search result found. Please try another input
| Unladen weight EU in kg | 1,485-1,475 [1,505-1,495] |
|---|---|
| Max. permissible weight in kg | 1,985 [2,005] |
| Permitted load in kg | 575-585 [575-585] |
| Permitted axle load front/rear in kg | 1,000/1,020 [1,020/1,020] |
| Luggage capacity min. (seats up or roof down) in l | 470 [470] |
| Luggage capacity max. (seats down or roof up) in l | 1,355 [1,355] |
| Trailer load (unbraked) in kg | 735-740 [745-750] |
| Trailer load 8% (braked) in kg | 1,400-1,700 [1,400-1,700] |
| Trailer load 12% (braked) in kg | 1,400-1,700 [1,400-1,700] |
| Cylinders/valves | 3/4 |
|---|---|
| Capacity in ccm | 1,499 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power* in kW (hp) at 1/min | 100-103 (136-140)/4,500-6,500 |
| Engine torque (Nm) at 1/min | 220/1,480-4,200 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 205 [205] |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 9.6 [9.6] |
| Urban in l/100 km | 7.3 [7.6] |
|---|---|
| Extra-urban in l/100 km | 5.4 [5.5] |
| Combined in l/100 km | 6.1 [6.3] |
| CO2 combined emissions in g/km | 139 [143] |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,545-1,535 |
|---|---|
| Max. permissible weight in kg | 2,055 |
| Permitted load in kg | 585-595 |
| Permitted axle load front/rear in kg | 1,055/1,030 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,355 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power* in kW (hp) at 1/min | 131-141 (178-192)/5,000-6,000 |
| Engine torque (Nm) at 1/min | 280/1,350-4,600 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 227 |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 7.7 |
| Urban in l/100 km | 7.6-7.4 |
|---|---|
| Extra-urban in l/100 km | 5.5-5.3 |
| Combined in l/100 km | 6.3-6.0 |
| CO2 combined emissions in g/km | 143-138 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,640-1,625 |
|---|---|
| Max. permissible weight in kg | 2,145 |
| Permitted load in kg | 580-595 |
| Permitted axle load front/rear in kg | 1,085-1,090/1,090 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,355 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,000 |
| Trailer load 12% (braked) in kg | 2,000 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power* in kW (hp) at 1/min | 131-141 (178-192)/5,000-6,000 |
| Engine torque (Nm) at 1/min | 280/1,350-4,600 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 224 |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 7.4 |
| Urban in l/100 km | 8.6 |
|---|---|
| Extra-urban in l/100 km | 6.3 |
| Combined in l/100 km | 7.1 |
| CO2 combined emissions in g/km | 163 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 61 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,690-1,685 |
|---|---|
| Max. permissible weight in kg | 2.19 |
| Permitted load in kg | 575-580 |
| Permitted axle load front/rear in kg | 1,120/1,095 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,355 |
| Trailer load (unbraked) in kg | - |
| Trailer load 8% (braked) in kg | - |
| Trailer load 12% (braked) in kg | - |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power* in kW (hp) at 1/min | 225 (306)/5,000-6,250 |
| Engine torque (Nm) at 1/min | 450/1,750-4,500 |
| Compression ratio : 1 | 9.5 |
| Top speed in km/h | 250 |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 4.9 |
| Urban in l/100 km | 9.2-8.7 |
|---|---|
| Extra-urban in l/100 km | 6.3 |
| Combined in l/100 km | 7.5-7.2 |
| CO2 combined emissions in g/km | 171-164 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 61 |
| Tyre dimensions front | 225/45 R19 96 W XL |
|---|---|
| Tyre dimensions rear | 225/45 R19 96 W XL |
| Wheel dimensions and material front | 8 J x 19 inches, light-alloy |
| Wheel dimensions and material rear | 8 J x 19 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,550 [1,570] |
|---|---|
| Max. permissible weight in kg | 2,015 [2,030] |
| Permitted load in kg | 540 [535] |
| Permitted axle load front/rear in kg | 1,035/1,055 [1,055/1,055] |
| Luggage capacity min. (seats up or roof down) in l | 470 [470] |
| Luggage capacity max. (seats down or roof up) in l | 1,355 [1,355] |
| Trailer load (unbraked) in kg | 750 [750] |
| Trailer load 8% (braked) in kg | 1,700 [1,700] |
| Trailer load 12% (braked) in kg | 1,700 [1,700] |
| Cylinders/valves | 3/4 |
|---|---|
| Capacity in ccm | 1496 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power* in kW (hp) at 1/min | 85 (116)/4,000 |
| Engine torque (Nm) at 1/min | 270/1,750-2,250 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 192 [192] |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 11.5 [11.5] |
| Urban in l/100 km | 5.2 [5.2] |
|---|---|
| Extra-urban in l/100 km | 4.4 [4.5] |
| Combined in l/100 km | 4.7 [4.8] |
| CO2 combined emissions in g/km | 124 [125] |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | |
| Growth capacity of lithium–ion battery in kWh | |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | |
| Electric Engine torque (Nm) at 1/min | |
| Combined system power | Combined system power |
| Combined power kW (PS) | |
| Combined torque Nm |
| Unladen weight EU in kg | 1,585 [1,615] |
|---|---|
| Max. permissible weight in kg | 2,080 [2,115] |
| Permitted load in kg | 570 [575] |
| Permitted axle load front/rear in kg | 1,060/1,050 [1,100/1,050] |
| Luggage capacity min. (seats up or roof down) in l | 470 [470] |
| Luggage capacity max. (seats down or roof up) in l | 1,355 [1,355] |
| Trailer load (unbraked) in kg | 750 [750] |
| Trailer load 8% (braked) in kg | 1,800 [1,800] |
| Trailer load 12% (braked) in kg | 1,800 [1,800] |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power* in kW (hp) at 1/min | 100-110 (136-150)/4,000 |
| Engine torque (Nm) at 1/min | 350/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 207 [207] |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 9.3 [9.3] |
| Urban in l/100 km | 5.6 [5.6] |
|---|---|
| Extra-urban in l/100 km | 4.5 [4.5] |
| Combined in l/100 km | 4.9 [4.9] |
| CO2 combined emissions in g/km | 129 [129] |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,680 |
|---|---|
| Max. permissible weight in kg | 2,180 |
| Permitted load in kg | 585 |
| Permitted axle load front/rear in kg | 1,115/1,100 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1.355 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1.8 |
| Trailer load 12% (braked) in kg | 1.8 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power* in kW (hp) at 1/min | 100-110 (136-150)/4,000 |
| Engine torque (Nm) at 1/min | 350/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 206 |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 9.4 |
| Urban in l/100 km | 5.7 |
|---|---|
| Extra-urban in l/100 km | 4.9 |
| Combined in l/100 km | 5.2 |
| CO2 combined emissions in g/km | 137 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,620 |
|---|---|
| Max. permissible weight in kg | 2,125 |
| Permitted load in kg | 580 |
| Permitted axle load front/rear in kg | 1,100/1,060 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1.355 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1.8 |
| Trailer load 12% (braked) in kg | 1.8 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power* in kW (hp) at 1/min | 140 (190)/4,000 |
| Engine torque (Nm) at 1/min | 400/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 224 |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 7.9 |
| Urban in l/100 km | 5.4 |
|---|---|
| Extra-urban in l/100 km | 4.6 |
| Combined in l/100 km | 4.9 |
| CO2 combined emissions in g/km | 128 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,680 |
|---|---|
| Max. permissible weight in kg | 2,190 |
| Permitted load in kg | 585 |
| Permitted axle load front/rear in kg | 1,120/1,100 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,355 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,000 |
| Trailer load 12% (braked) in kg | 2,000 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power* in kW (hp) at 1/min | 120-140 (163-190)/4,000 |
| Engine torque (Nm) at 1/min | 400/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 221 |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 7.7 |
| Urban in l/100 km | 5.7 |
|---|---|
| Extra-urban in l/100 km | 4.9 |
| Combined in l/100 km | 5.2 |
| CO2 combined emissions in g/km | 137 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,695 |
|---|---|
| Max. permissible weight in kg | 2,170 |
| Permitted load in kg | 550 |
| Permitted axle load front/rear in kg | 1,140/1,080 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,355 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,000 |
| Trailer load 12% (braked) in kg | 2,000 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power* in kW (hp) at 1/min | 170 (231)/4,400 |
| Engine torque (Nm) at 1/min | 450/1,500-3,000 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 237 |
|---|---|
| Electrical engine top speed in km/h | - |
| Acceleration 0–100 km/h in s | 6.6 |
| Urban in l/100 km | 5.9 |
|---|---|
| Extra-urban in l/100 km | 5.1 |
| Combined in l/100 km | 5.4 |
| CO2 combined emissions in g/km | 141 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 51 |
| Tyre dimensions front | 225/55 R17 97 W |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 W |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Range and charging | Range and charging |
| Electric range in km (NEDC) | - |
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine | Electric engine |
| Electric engine power kW (PS) at 1/min | - |
| Electric Engine torque (Nm) at 1/min | - |
| Combined system power | Combined system power |
| Combined power kW (PS) | - |
| Combined torque Nm | - |
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW X2 xDrive20i:
Fuel consumption in l/100 km (combined): 7.6–6.9
CO2 emissions in g/km (combined): 174–156
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW X2 xDrive20i:
Fuel consumption in l/100 km (combined): 7.1
CO2 emissions in g/km (combined): 163
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
